LED TP-luminaire 1,5m 50W SCCT 120° multi power
Damp-proof luminaire
.ldt)
.ldt)
.ldt)
.ldt)
SKU:
1621501047
EAN: 4044538074887
EAN: 4044538074887
The moisture-proof LED damp-proof luminaire with IP65 protection is perfectly suitable for the application area such as workshop, garage, basement, laundry room, as well as in the outdoor area. Thanks to SCCT technology, the color temperature can be selected in advance before installing the luminaire.
Through the multi-power function, it is also possible to adjust the luminous flux in two stages before installation. The damp-proof luminaire has a long service life and is energy-efficient. Multiple damp-proof luminaires can be interconnected via through-wiring.
Material: PC
Dimension (LxWxH): 1570x60x70 mm
Color rendering index Ra: 80
Color distance (MacAdam): 3 SDCM
Lifetime: 50.000 h (L80 B10)
weniger lesen
Technical Data
-
Temperature specifications
Ambient temperature [Ta] [°C] -20 - 45 - Material and colour
Material housing PC and ABS Colour housing grey Housing colour (RAL) 7035 Material diffuser PC Diffuser surface opal - Product contents
With light source yes - Dimensions and weight
Length [mm] 1570 Width [mm] 60 Height [mm] 70 Weight [g] 780 - Technical lighting specifications
LED efficiency [system] [lm/W] 120 Light cone Extreme wide beam >80° Suitable for number of light sources 1 Colour temperature 2 [K] 5700 Colour temperature [K] 4000 Total luminous flux [lm] 6000 Total luminous flux 2 [lm] 3600 Beam angle [°] 120 Colour consistency [MacAdam] [SDCM] 3 Colour rendering index Ra 80 Colour rendering index R9 15 Light distributor without L80B10 - life time at 25 °C [h] 50000 L70B50 - life time at 25°C [h] 60000 Flicker Metric [Pst LM] 0,005 Total lumen setting adjustable Positions Colour temperature adjustable Positions Constant light output (CLO) no Light source replaceable no Light sharing symmetric Light outlet direct Lamp type SMD-LED - Other specifications
Operation by Bluetooth no BEG funding yes Type of luminaire industrial light Suitable for suspended mounting yes Kind of disposal at the end of the life time specific collection points, please consider the local regulations Reflector without - Protection specifications
Saltwater resistant yes CE-Conformity yes RoHS yes Protection class I Degree of protection IP65 Impact strength IK09 Ball-prrof no Short-circuit protected yes Protection against overheating yes Temperature protection shutdown at [°C] 110 Photobiological safety according to EN 62471 RG0 Filament test according to IEC 60695-2-10 [°C] 650 ENEC-Test mark ENEC 05 With protective cover yes Ammonia resistant no Sulphur resistant no Luminaire with limited surface temperature, sign 'D“ yes Installation, electrical engineering expertise yes Fire resistance 'D' yes - Electrical specifications
Lamp power [W] 50 Lamp power 2 [W] 30 Voltage type AC Input frequency [Hz] 50 - 60 Power factor [at full load] 0,9 Quantity on MCB B16 (max.) 29 Quantity on MCB C16 (max.) 29 Total harmonic distortion 0,2 Lamp holder without Type of wiring Suitable for through wiring Cable conductor quantity primary 3 Exchangeable LED driver no Dimmable no Flicker free yes Driver integrated yes Input voltage [AC] [V] 220 - 240 Number of poles 3
